Report

The report module provides functionality for to report model data to disk. This can be configured in model.yml under the report key. The structure is as follows:

report:
    module_name:
        filename:
            varname: varname
            type: type
            function: function
            frequency: frequency  # optional
        other_filename:
            varname: varname
            type: type
            function: function
            frequency: frequency  # optional
    other_module_name:
        filename:
            varname: varname
            type: type
            function: function
            frequency: frequency  # optional

For example, to export the total bare soil evaporation, gridded daily discharge, and the mean channel abstraction by crop_farmers, you would use the following configuration:

report:
    hydrology.soil:
        actual_bare_soil_evaporation_weighted_sum:
            varname: .actual_bare_soil_evaporation
            type: HRU
            function: weightednansum
    hydrology.routing:
        discharge_daily:
            varname: grid.var.discharge
            type: grid
            function: null
    agents.crop_farmers:
        channel_abstraction_m3_by_farmer_mean:
            varname: var.channel_abstraction_m3_by_farmer
            type: agents
            function: mean

The following options are supported.

module_name: The name of the module in the GEB model. Both agents and hydrological modules are supported. Please refer to the name property of the module for the correct names.
filename: The name of the file to be created. This can be a .csv or .zarr file. If the file already exists, it will be overwritten. The filename will be created in the output directory specified in the model configuration file, and placed inside the subdirectory with the name of the module.
varname: The name of the variable to be reported. NumPy-style fancy indexing is supported. For example varname[:,0] selects the first column of a 2D array. There are two options:
- module attribute: The variable name in the module. Any variable that can be reached from “self” in the module can be used. For example, [self.]varname or [self.]grid.var.discharge. Note that self. is ommited.
- local variable: Any variable that exists within the step function of the module. This is useful for reporting variables that are not stored between timesteps. Local variables are prefixed with “.”, for exampe .actual_bare_soil_evaporation in the example above.
type: The type of the variable. This can be one of the following:
- grid: A variable that is stored in the grid structure of GEB.
- HRU: A variable that is stored in the hydrological response unit (HRU) structure of GEB.
- agents: A variable that is stored in the agents. This is a 1D array with the same length as the number of agents. The variable will be reported as a 1D array.
function: The function to be used to process the variable before reporting. The supported options vary per type. Each type supports the null function, which means that no function is applied and the variable is reported as is in a zarr file. In all other cases the variable is reported at the end of the model run in a csv file. The following functions are supported:
- agents:
  - null: No function is applied. The variable is reported as is.
  - mean: The mean of the variable is calculated and reported.
  - nanmean: The mean of the variable is calculated and reported, ignoring NaN values.
  - sum: The sum of the variable is calculated and reported.
  - nansum: The sum of the variable is calculated and reported, ignoring NaN values.
- grid and HRU:
  - null: No function is applied. The variable is reported as is.
  - mean: The mean of the variable is calculated and reported.
  - nanmean: The mean of the variable is calculated and reported, ignoring NaN values.
  - sum: The sum of the variable is calculated and reported.
  - nansum: The sum of the variable is calculated and reported, ignoring NaN values.
  - weightedmean: The mean of the variable is calculated and reported, weighted by the grid cell area.
  - weightednanmean: The mean of the variable is calculated and reported, weighted by the grid cell area, ignoring NaN values.
  - sample,[y],[x]: Sample a specific variable at specific y,x pixel. 0,0 is the top left corner of the grid. Example is sample,1,2 to sample the variable at pixel 1,2.
  - sample_coord,[lat],[lon]: Sample a specific variable at specific coordinates using the lat,lon coordinates of the grid. The coordinates are in the same coordinate system as the grid. Example is sample_coord,52.38,4.89 to sample the variable at coordinates latitude 52.38 and longitude 4.89 (Amsterdam). Note that when reporting discharge, it is important to make sure that the location is in the actual river you want to sample from. You can refer to the upstream area in the input files to find the actual river.
frequency (optional): The frequency at which the variable is reported. The default is every: day This can be one of the following:
- initial: The variable is reported at the initial time step only.`
- final: The variable is reported at the final time step only.
- every: The variable is reported at specified timesteps, examples are given below.

Report the data every third day of the month:

report:
    module_name:
        filename: filename
        varname: varname
        type: type
        function: function
        frequency:
            every: month
            day: 3

Report every 15th of March every year:

report:
    module_name:
        filename: filename
        varname: varname
        type: type
        function: function
        frequency:
            every: year
            month: 3
            day: 15

Package contents

class Reporter(model)[source]

This class is used to report data to disk.

Parameters:: model – The GEB model.

create_variable(config, module_name, name)[source]

This function creates a variable for the reporter. For configurations without a aggregation function, a zarr file is created. For configurations with an aggregation function, the data is stored in memory and exported on the final timestep.

Parameters:

config (dict) – The configuration for the variable.
module_name (str) – The name of the module to which the variable belongs.
name (str) – The name of the variable.

Return type:

None

finalize()[source]

At the end of the model run, all previously collected data is reported to disk.

Return type:: None

maybe_report_value(module_name, name, module, local_variables, config)[source]

This method is used to save and/or export model values.

Parameters:

name (Union[str, tuple[str, Any]]) – Name of the value to be exported.
value – The array itself.
conf – Configuration for saving the file. Contains options such a file format, and whether to export the data or save the data in the model.

Return type:

None

process_value(module_name, name, value, config)[source]

Exports an array of values to the export folder.

Parameters:

module_name (str) – Name of the module to which the value belongs.
name (str) – Name of the value to be exported.
value (ndarray) – The array itself.
conf – Configuration for saving the file. Contains options such a file format, and whether to export the array in this timestep at all.

Return type:

None

report(module, local_variables, module_name)[source]

This method is in every step function to report data to disk.

Parameters:

module – The module to report data from.
variables – A dictionary of local variables from the function that calls this one.
module_name – The name of the module.

Return type:

None

create_time_array(start, end, timestep, conf)[source]

Create a time array based on the start and end time, the timestep, and the frequency.

Parameters:

start (datetime) – The start time.
end (datetime) – The end time.
timestep (timedelta) – The timestep length.
conf (dict) – The configuration for the frequency.

Returns:

time – The time array.

Return type:

list
